Power & Performance

• Design: Single-driver, acoustic suspension (sealed) reference subwoofer
• Crossover: Low-pass filter, variable 30 Hz – 140 Hz (with bypass option via app)
• Frequency Response (On-Axis): +/- 3 dB from 17 Hz – 140 Hz
• Frequency Response (30° Off-Axis): N/A (Subwoofer omnidirectional execution)
• Sensitivity (Room / Anechoic): N/A (Active subwoofer execution)
• Impedance: N/A (Driven internally by dedicated active amplifier plant)
• Low Frequency Extension: 12 Hz (DIN)
• Suitable Amplifier Power Range: N/A (Active design)
• Maximum Input Power: 2,200 Watts RMS / 4,400 Watts Dynamic Peak (Ultra-High-Efficiency Class-D)
• Performance: The Paradigm XR13 is the absolute pinnacle of Paradigm's standalone low-frequency engineering, built to anchor the world's finest home theater and audiophile systems. This unrelenting sealed titan forces out a colossal 2,200W RMS internal power reservoir to control an oversized 13-inch Carbon-X™ unibody driver. By achieving a seismic 12 Hz low-frequency extension, the XR13 produces the tectonic pressure fields usually reserved for massive, cumbersome ported enclosures—all while keeping a beautifully refined, living-room-friendly physical cabinet blueprint. It is the definitive choice for grand reference cinemas and zero-compromise listening spaces, providing devastating cinematic physical slams alongside lightning-fast, textured, and analytical musical bass lines.

Audio Features & Drivers

• 13-inch Ultra-High-Excursion CARBON-X™ Unibody Bass Driver: Formed from a single, seamless piece of carbon-fiber-reinforced composite matrix. This unibody cone minimizes moving mass while delivering extreme structural stiffness, completely resisting flexing or warping under brutal multi-layered cinematic demands.
• Dual-Motor Ultra Long Throw Trilinear Suspension: A massive multi-motor platform supported by a heavy-duty dual-spider centering layout. This vertical mounting geometry mechanically guides the massive voice coil from both sides, guaranteeing perfectly straight piston alignment even when pushing the driver to its absolute physical stroke boundaries.
• Extreme-Stiffness Split Coil Construction: Features two voice coils wound with opposing turns on a rigid, ventilated Apical™ former. This design effectively cancels out physical motor non-linearities, allowing the driver to process high electrical current safely while remaining exceptionally controlled.
• High-Temperature Voice Coil Wiring: The motor assemblies utilize specialized heavy-gauge internal wire leads insulated with aerospace-grade adhesives rated to 450°F (232°C). This design feature prevents long-duration thermal power compression artifacts under peak loads.
• Gen3 ART™ (Active Ridge Technology) Surrounds: The 13-inch driver features overmolded thermoplastic elastomer surrounds utilizing a specialized Vertical Mounting System. This pleated edge allows for maximum linear throw without distortion or destruction, yielding a critical 3 dB gain in clean output headroom.

Streaming & Connectivity

• Flexible Input Signal Panel: Fully loaded with dual unbalanced RCA inputs (Stereo or Mono LFE), a balanced premium XLR (LFE) connection, and left/right speaker-level high-input binding terminals to adapt to any stereo pre-amplifier or multi-channel AV processor.
• Isolated Signal Input Grounding: The entire rear terminal block is structurally isolated from internal AC loop paths, completely eliminating the common "subwoofer hum" caused by ground loop anomalies.
• Comprehensive Wireless Control App: Features a dedicated mobile control app available on iOS and Android. This allows users to easily manage master volume, phase (0°-180°), low pass filter slope, and a customized tone sweep straight from their main listening seat.
• Anthem Room Correction (ARC® Genesis): Includes a premium calibrated microphone and full access to ARC® Genesis software. This system digitally analyzes your specific room reflections, ironing out bloated standing bass waves caused by nearby furniture or boundary corners.
• Capacitive Touchscreen Control: Employs a flush, sleek touch control interface embedded directly into the top rear amplifier face plate, allowing for easy manual volume adjustments without a smartphone.

Comfort & Dimensions

• Advanced Shock-Mount™ Isolation Feet: Supported by heavy-duty, multi-layered outrigger feet that combine different durometer rubbers and metal matrices to decouple the cabinet from the floor. This system keeps intense box vibrations from bleeding into nearby structures, making it highly neighbor-friendly while tightening up bass control.
• Bespoke Luxury Cabinets: Showcases furniture-grade woodworking available in distinct, elegant treatments—including hand-glossed Piano Black and Midnight Cherry lacquers, or satin Walnut and Black Walnut wood veneers.
• Overall Dimensions: 18.8” (47.8cm) Height x 17.3” (43.8cm) Width x 19.4” (49.3cm) Depth.
• Unit Weight: 103.8 lbs (47.1 kg) each — A massive, ultra-solid footprint reflecting the thick 2-inch MDF front baffle plane, dense internal reinforcement matrices, and a monumental internal magnet motor structure.
• Sonically Transparent Fabric Grille: Includes an ultra-low-profile grille frame wrapped in acoustically transparent black cloth, keeping the face of the subwoofer looking clean and minimal.

Design & Build

• Cascade-Fusion™ Enclosure Bracing: The interior features thick, non-uniform internal reinforcement webs that break up internal back-wave pressure pulses, preventing the sealed box from flexing or coloring the acoustic workspace.
• 2-Inch Thick Dense MDF Front Baffle: The face of the cabinet is constructed from an ultra-thick, machined 2-inch MDF slab. This serves as an unyielding structural backbone to withstand the violent forces generated by the 13-inch woofer.
• Finned Aluminum Heat Sink: The rear plate amplifier is equipped with a custom-finned heavy exterior aluminum heat sink that channels thermal energy away from the Class-D electronics module for years of reliable, cool operation.
• 3-Mode Custom DSP Matrix: Loaded with three tailored listening profiles: Movie (maximizing low-end impact), Music (prioritizing tight, flat-line accuracy), and Night (compressing dynamic peaks to prevent sound bleed into nearby bedrooms).
• Hand-Built in Canada: Fully engineered, prototyped, and meticulously hand-assembled under rigid quality controls at Paradigm’s premier manufacturing plant in Ontario, Canada.

Paradigm speakers are warranted to be and remain free of manufacturing and/or material defects for a period of outlined below from the date of original purchase. Within the time period specified, repair, replacement or adjustment of parts for manufacturing and/or material defects will be free of charge to the original owner. Thermal or mechanical abuse/misuse is not covered under warranty.

The warranty period on Paradigm speakers is as follows:

• Bookshelf, floorstanding, in-wall & in-ceiling speakers — five (5) years
• Powered Subwoofers — three (3) years
• Outdoor Rock speakers — five (5) years
• Stylus Outdoor speakers — two (2) years
• Powered Speakers — one (1) year
• SHIFT Series products — one (1) year

Warranty begins on date of purchase from Paradigm or an Authorized Paradigm Dealer.

This warranty applies only to purchases made from authorized Paradigm dealers in Canada and the United States. For warranty terms, conditions and support elsewhere, please contact the authorized Paradigm distributor in the country where you made your purchase. Warranty outside Canada and the US is established and provided by our authorized distributors around the world.

Limitations:

• Warranty begins on date of original retail purchase from an Authorized Paradigm® Dealer only. It is not transferable;
• Warranty applies to product in normal home use only. If product is subjected to any of the conditions outlined in the next section, warranty is void;
• Warranty does not apply if the product is used in professional or commercial applications.

Warranty is Void if:

• The product has been abused (intentionally or accidentally);
• The product has been used in conjunction with unsuitable or faulty equipment;
• The product has been subjected to damaging signals, derangement in transport, mechanical damage or any abnormal conditions;
• The product (including cabinet) has been tampered with or damaged by an unauthorized service facility;
• The serial number has been removed or defaced.

Owner Responsibilities:

• Provide normal/reasonable operating care and maintenance;
• Provide or pay for transportation charges for product to service facility;
• Provide proof of purchase (your sales receipt given at time of purchase from your Authorized Paradigm® Dealer must be retained for proof-of purchase date).

Should servicing be required, contact your nearest Authorized Paradigm® Dealer, Paradigm Electronics Inc. or Import Distributor (outside the U.S. and Canada) to arrange, bring in or ship prepaid, any defective unit. Paradigm Electronics Inc. reserves the right to improve the design of any product without assuming any obligation to modify any product previously manufactured. This warranty is in lieu of all other warranties expressed or implied, of merchantability, fitness for any particular purpose and may not be extended or enlarged by anyone. In no event shall Paradigm Electronics Inc., their agents or representatives be responsible for any incidental or consequential damages. Some jurisdictions do not allow limitation of incidental or consequential damages, so this exclusion may not apply to you.

Retain your sales receipt for proof of warranty term and proof of purchase.
